| Product type | Mixers |
| Type | Installations, stereo |
| Number of Zones | 2 (Master, Zone) |
| Type | Installations, stereo |
| Installation Height | 1 U |
| Total Input Channels | 8 (2x Mic, 2x Mic/Line, 3x Line, 1x FOH) |
| Frequency response | 20 - 40000 Hz |
| Microphone channels | 2 (with phantom power 12 V) |
| Microphone Channel Connections | 6.3 mm stereo jack (balanced) |
| Microphone channel controls | 1 x EQ Hi, 1 x EQ Low, 1 x Talk Over Damp, 1 x Talk Over Level, Gain, On / Off |
| Microphone Channels Display Elements | On-LED |
| Microphone Channels Input Impedance | 4 kOhm |
| Microphone Channels Input Sensitivity | 6.1 mV |
| Microphone Channels THD | 0.08% |
| Line / Microphone Channels | 2 |
| Line / microphone input connectors | 2 x RCA, 3.5 mm stereo jack (input 1), 6.3 mm stereo jack (balanced) |
| Line / microphone channel controls | Cue, level, mic/lline, Trim |
| Line / Microphone Display Elements | Cue-LED, Signa-LED |
| Line Channels | 3 |
| Line input connectors | Input 3-4: 2 x RCA, Input 5: 2 x RCA + USB |
| Line Channel Controls | Cue, level, Trim |
| Line Channel Display Elements | Cue-LED, Signa-LED |
| Line Channel Input Impedance | 4 kOhm |
| Line Channels Input Sensitivity | 1.5 V |
| Line Channels THD | 0.03% |
| input sensitivity AUX/Line | 3 V |
| FOH Channels | 1 |
| FOH Input Connections | 6.3 mm stereo jack (2 x balanced) |
| FOH Input Controls | Cue, level |
| FOH Input Display Elements | Cue-LED, Signa-LED |
| Line outputs | 3 (Master - Stereo, Zone - Mono, Rec - Stereo) |
| Output Connectors Master | 6.3 mm stereo jack (2 x balanced), RCA (x2), terminal block |
| Master Controls | EQ Hi, EQ Low, level, Max. Level |
| Master Display Elements | 5-Segment Level Meter |
| Master Output Levels | (balanced) 24 dBu, (unbalanced) 18 dBu |
| Zone Output Connections | 6.3 mm stereo jack (balanced), terminal block |
| Zone Controls | EQ Hi, EQ Low, level, Max. Level, Source Input 1-5/Mix |
| Zone Display Elements | 5-Segment Level Meter |
| Zone Output Levels | 24 (balanced/ unbalanced) dBu |
| Output Connections Rec | 2 x RCA |
| Headphones ouput | 1 |
| Headphone Out Port | 6.3 mm TRS |
| Headphone Output Controls | Cue Volume |
| Headphone Output Voltage | (@ 32 Ohm) 1.25 V |
| Additional Inputs | 2 (Emergency Input, Output Mute) |
| Connections Additional Inputs | terminal block |
| Additional Input Controls | Level Emergency Input |
| Additional Controls | power switch |
| Additional Display Elements | Power-LED |
| Operating voltage | 220 - 250 V AC, 50 Hz |
| Mains connector | IEC power connector |
| Power consumption | 18 W |
| Fuse | T 500 mAL / 250 V |
| Width | 485 mm |
| Height | 44 mm |
| Depth | 179 mm |
| Weight | 2,4 kg |
| Accessories (included) | Power cord, terminal blocks |
Odkaz na stránky výrobce Ld Systems
