| Product type | Mixers |
| Type | Installations, stereo |
| Number of Zones | 4 (Master, Zone A-C) |
| Type | Installations, stereo |
| Installation Height | 3 U |
| Total Input Channels | 8 (2x Mic, 1x AUX/Line, 2x Phono/Line, 2x Line, 1x FOH/Line |
| Frequency response | 20 - 40000 Hz |
| Microphone channels | 2 (with phantom power 12 V) |
| Microphone Channel Connections | 6.3 mm stereo jack (2 x balanced), XLR |
| Microphone channel controls | 1 x EQ Hi, 1 x EQ Low, 1 x Talkover, 1x EQ Mid, 2 x gain, 2x On/Off |
| Microphone Channels Display Elements | On-LED |
| Microphone Channels Input Impedance | 4 kOhm |
| Microphone Channels Input Sensitivity | 4.5 mV |
| Microphone Channels THD | 0.08 % |
| Line Channels | 6 (Input 1: Aux/Line, Input 2 + 5: Line/Phono, Input 3: USB/Line 4: Line, Input 6: Line/FOH |
| Line input connectors | input 2, 4 5: 2 x RCA, Input 1: 2 x RCA + 3.5 mm stereo jack, input 3: 2 x RCA + USB, input 6: 4 x RCA + 2 x 6.3 mm jack |
| Line Channel Controls | 2x Phono/Line, AUX enable, Cue, FOH On, Gain, level |
| Line Channel Display Elements | Cue-LED, Signal/0 dB-LED |
| Line Channel Input Impedance | (Phono) 50 kOhm, 6 kOhm |
| Line Channels Input Sensitivity | (Phono) 25m V, 2.1 V |
| Line Channels THD | (Phono) 0.05%, 0.02% |
| input sensitivity AUX/Line | 3 V |
| Line outputs | 5 (Master - Stereo, 3x Zone - Mono, Rec - Stereo) |
| Output Connectors Master | 2 x XLR (balanced), RCA (x2), terminal block |
| Master Controls | EQ Hi, EQ Low, EQ Mid, level, Max. Level, T/O Damping, T/O Sensitivity |
| Master Display Elements | 2 x 10 segment level meter |
| Master Output Levels | (balanced) 24 dBu, (unbalanced) 17 dBu |
| Zone Output Connections | terminal block, XLR (balanced) |
| Zone Controls | 100 Hz High Pass, Cue, EQ Hi, EQ Low, Include Mic, level, Max. Level, Source, T/O Damp |
| Zone Display Elements | 5-Segment Level Meter |
| Zone Output Levels | 24 (balanced/ unbalanced) dBu |
| Output Connections Rec | 2 x RCA |
| Headphones ouput | 1 |
| Headphone Out Port | 6.3 mm TRS |
| Headphone Output Controls | Cue Volume |
| Headphone Output Voltage | (@ 32 Ohm) 2.5 V |
| Additional Inputs | 2 (Emergency Input, Output Mute) |
| Connections Additional Inputs | terminal block |
| Additional Input Controls | Level Emergency Input |
| Input Sensitivity Emergency Input | 5 V |
| Additional Controls | power switch |
| Additional Display Elements | Power-LED |
| Operating voltage | 220 - 250 V AC, 50 Hz |
| Mains connector | IEC power connector |
| Power consumption | 25 W |
| Fuse | T 500 mAL / 250 V |
| Width | 485 mm |
| Height | 132 mm |
| Depth | 210 mm |
| Weight | 4,4 kg |
| Accessories (included) | Power cord, terminal blocks |
Odkaz na stránky výrobce Ld Systems
